ISO Range
|
ISO 100 - 51,200 Can also be set to approx. 0.3, 0.5, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.5, 0.7, 1, or 2 EV (ISO 204,800 equivalent) above ISO 51,200; auto ISO sensitivity control available
|
Sensors
Sensors are electronic components that detects and responds to some type of input from the physical environment. The specific input could be light, heat, motion, moisture, pressure and location, The output is generally a signal that is converted to use in computing systems, a location sensor, such as a GPS receiver is able to detect current location of your electronic device.
|
Sensor Size : 35.9 mm x 23.9 mm ; Image Sensor Format : FX ; Image Sensor Type : CMOS
|
White Balance
|
Auto (3 types) Choose color temperature (2500K to 10000K) Cloudy Direct Sunlight Flash Fluorescent (7 types) Incandescent Natural Light Auto Preset manual (up to 6 values can be stored, spot white balance measurement available during live view) Shade All except choose color temperature with fine-tuning
|
Format
|
JPEG: JPEG-Baseline compliant with fine (approx 1:4), normal (approx 1:8), or basic (approx 1:16) compression (size priority); Optimal quality compression available NEF (RAW) + JPEG: single photograph recorded in both NEF (RAW) and JPEG Formats NEF (RAW): lossless compressed, compressed 12 or 14 bit
|
Focus
|
Detection Range : Viewfinder photography: -3 to +19 EV Live view: -5 to +19 EV; -7 to +19 EV with low-light AF Figures are for ISO 100 at 20 °C/68 °F Still photography using single-servo AF (AF-S) and apertures of f/1.4 at dark end of range and f/5.6 at bright end of range; ISO 100; 20 °C/68 °F ; Focus : Focus Lock Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing A (AE-L/AF-L) button
|
Lens Mount
|
Nikon F bayonet mount
|
Viewfinder
|
Eye-level Pentaprism Single-Lens Reflex Viewfinder ; Frame Coverage : FX (36x24): 100% horizontal and 100% vertical (Approx.) 1.2x (30x20): 97% horizontal and 97% vertical (Approx.) DX (24x16): 97% horizontal and 97% vertical (Approx.)
|
Shutter
|
Electronically controlled vertical-travel focal-plane Electronic front-curtain shutter available in quiet shutter-release, quiet continuous shutter-release, and mirror up release modes Mechanical shutter ; Shutter Speed : 1/8000 to 30 sec. in steps of 1/3 or 1/2 EV, extendable to 900 sec. in mode M; Bulb; Time; X200
|
Apeture
|
Instant-return type-Electronically; controlled
|
Exposure
|
Aperture-Priority (A) Manual (M) Programmed auto with flexible program (P) Shutter-Priority (S) Special Effects Modes (night vision- super vivid- pop- photo illustration- toy camera effect- miniature effect- selective color- silhouette- high key- low key) U1 (user setting 1) U2 (user setting 2)
|
Flash
Flash Light => There is commonly two types of flash lights are used in camera mobile phones, LED Flash (LED flash offers lower power consumption with drive circuitry that takes up very little room, LEDs can be strobed faster than any other light source), Xenon Flash (xenon flash produces an extremely intense full-spectrum white light for a very short duration)
|
Viewfinder photography: TTL flash control performed by RGB sensor with approximately 180K (180,000) pixels Live view photography: TTL flash control performed by image sensor (i-TTL balanced fill-flash for digital SLR used with matrix, center-weighted, and highlightweighted metering- standard i-TTL fill-flash for digital SLR supported)
|
Self Timer
|
2, 5, 10, 20 sec.; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 sec. Timer duration electronically controlled
|
Metering Modes
|
Center-weighted: Weight of 75% given to 12 mm circle in center of frame. Diameter of circle can be changed to 8, 15, or 20 mm, or weighting can be based on average of entire frame (non-CPU lenses use 12-mm circle) Matrix: 3D Color Matrix Metering II (type G, E, and D lenses); Color Matrix Metering II (other CPU lenses); Color Matrix Metering available with non-CPU lenses if user provides lens data Spot: Meters 4 mm circle (about 1.5% of frame) centered on selected focus point (on center focus point when non-CPU lens is used) Highlight-weighted: Available with type G, E, and D lenses; equivalent to center-weighted when non-CPU lens is used
|
Video -Features
|
Movie Metering : TTL exposure metering using main image sensor ; Movie File Format : MOV ; Movie Video Compression : H.264/MPEG-4 Advanced Video Coding ; Movie Audio Recording Format : Linear PCM ; 4K UHD 3,840x2,160 / 30 fps , 4K UHD 3,840x2,160 / 25 fps , 4K UHD 3,840x2,160 / 24 fps , Full HD 1,920x1,080 / 120 fps, Full HD 1,920x1,080 / 100 fps, Full HD 1,920x1,080 / 60 fps Full HD 1,920x1,080 / 50 fps, Full HD 1,920x1,080 / 30 fps, Full HD 1,920x1,080 / 25 fps , Full HD 1,920x1,080 / 24 fps , Slow-motion: Full HD 1,920x1,080 30p (x4) , Slow-motion: Full HD 1,920x1,080 25p (x4) Slow-motion: Full HD 1,920x1,080 24p (x5), Actual frame rates for 120p, 100p, 60p, 50p, 30p, 25p, and 24p are 119.88, 100, 59.94, 50, 29.97, 25, and 23.976 fps respectively , Quality selection available at all sizes except 3,840 x 2,160 (when quality is fixed at high) and 1,920 x 1,080 slow-motion (when quality is fixed at normal)
|
Storage Capacity
|
SD SDHC (UHS-II compliant) - SDXC (UHS-II compliant)
|
CONNECTIVITY
|
Audio input: Stereo mini-pin jack (3.5 mm diameter; plug-in power supported) HDMI output: Type C mini-pin HDMI connector Headphone Connector Hi-Speed USB Type C USB connector (SuperSpeed USB 3.1 Gen1) connection to built-in USB port is recommended
|
Environment
|
Operating Environment : 0–40 °C (+32–104 °F)
|
Battery
|
EN-EL15b Rechargeable Li-ion Battery EN-EL15a/EN-EL15 batteries can also be used. Note, however, that fewer pictures may sometimes be taken on a single charge with the EN-EL15 than with an EN-EL15b/EN-EL15a. EH-7P Charging AC adapter can be used to charge EN-EL15b batteries only - Battery Life : (shots per charge) 2,260 shots (CIPA)
|
